Lab Gas Generators

GTL-300/500 Combined Hydrogen, Nitrogen and Air Generator

Inquiry and Sales: or Online Request


Model GTL-300/500 combines nitrogen, hydrogen and air generators in one product. Developed with the latest technology and designed for the requirements of the market, GTL-300/500 combined Hydrogen, Nitrogen and Air generator offers the best quality and working conditions for the users.

  • High purity and fast gas generation;
  • Compact and portable;
  • Safety, reliability of operation and low noise are insured with help of multi-stage protective devices;
Model GTL-300 GTL-500
Purity of produced Air Three-stage purification
Purity of produced Nitrogen 99.999%
Purity of produced Hydrogen 99.999%
Output flow Hydrogen: 0 ~ 300 mL/min
Nitrogen : 0 ~ 300 mL/min
Air: 0 ~ 2 L/min
Hydrogen: 0 ~ 500 mL/min
Nitrogen: 0 ~ 500 mL/min
Air: 0 ~ 5 L/min
Output pressure 0 ~ 0. 5MPa (factory default setting: 0.5 ± 0.01MPa)
Power supply AC 220V/50Hz or 110V/60Hz
Maximum power consumption 350W 450W
